Products >> Pure Metals >> Magnesium Foil,Sheet,Disc,Wire,Rod

Magnesium Foil,Sheet,Disc,Wire,Rod

Product No.：2030
Online Inquiry

Magnesium (Mg) is a chemical element, its element symbol is Mg. Magnesium is a silvery white (sometimes it shows silver grey or grey surface finish arising from different processing way), light alkaline earth metal with the atomic number 12. It is chemically active and can react with acid to produce hydrogen, with certain ductility and heat dissipation. Magnesium element is widely distributed in nature and is one of the essential elements of human body.

Physical properties
Magnesium is one of the lightest structural metal materials. It also has the advantages of high specific strength and stiffness, good damping and machinability, easy recovery and so on. Magnesium come out a thin layer of oxide when exposed to air, which results in its color might show grey or even black.

Chemical properties

Magnesium has strong reducibility, it can react with boiling water to release hydrogen, and can produce dazzling white light during combustion. Magnesium does not interact with fluoride, hydrofluoric acid and chromic acid, but Magnesium is very easy to dissolve in organic and inorganic acids. Magnesium can be directly combined with nitrogen, sulfur and halogen. When magnesium burns in the air, it burns violently, emit dazzling white spotlight, release heat and generate white solid. The change in vinegar is that bubbles appear quickly. Float on the vinegar liquid and disappear gradually. Some fireworks and flares contain magnesium powder, which makes use of the dazzling white light of magnesium burning in the air.

Symbol:	Mg
Atomic Number:	12
Atomic Weight:	24.305
Density:	1.74 gm/cc
Melting Point:	648.8 ^oC
Boiling Point:	1090 ^oC
Thermal Conductivity:	1.56 W/cm/K @ 298.2 K
Electrical Resistivity:	4.45 microhm-cm @ 20 ^oC
Electronegativity:	1.2 Paulings
Specific Heat:	0.243 Cal/g/K @ 25 ^oC
Heat of Vaporization:	32.517 K-Cal/gm atom at 1090 ^oC
Heat of Fusion:	2.16 Cal/gm mole

Max Elements Production Lines for Magnesium Foil,Sheet,Disc,Wire,Rod, Magnesium oxide-Single Crystal Jul. 2022
Line Number	Material	Demensions	Quantity(Meter/PC)	Purity	Temper
MG2030-0596	Magnesium Foil	0.015mm ×150mm×150mm	1000pcs/2000pcs	99.95%	As Rolled
MG2030-0599	Magnesium Foil	0.015mm ×150mm×300mm	500pcs/1000pcs	99.95%	As Rolled
MG2030-0607	Magnesium Foil	0.015mm ×150mm×480mm	500pcs/1000pcs	99.95%	As Rolled
MG2030-0693	、、	0.025mm ×150mm×150mm	500pcs/1000pcs	99.95%	As Rolled
MG2030-0697	、、	0.025mm ×150mm×500mm	250pcs/500pcs	99.95%	As Rolled
MG2030-0703	、、	0.025mm ×150mm×1000mm	120pcs	99.95%	As Rolled
MG2030-0721	、、	0.05mm ×150mm×150mm	300pcs/600pcs	99.95%	As Rolled
MG2030-0727	、、	0.05mm ×150mm×500mm	100pcs/200pcs	99.95%	As Rolled
MG2030-0729	、、	0.05mm ×200mm×200mm	250pcs/500pcs	99.95%	As Rolled
MG2030-0731	、、	0.05mm ×150mm×1000mm	50pcs/100pcs	99.95%	As Rolled
MG2030-1070	、、	0.08mm ×120mm×500mm	100pcs/200pcs	99.95%	As Rolled
MG2030-1080	、、	0.08mm ×120mm×1000mm	50pcs/100pcs	99.95%	As Rolled
MG2030-1099	、、	0.1mm ×120mm×500mm	80pcs/160pcs	99.95%	As Rolled
MG2030-1104	、、	0.1mm ×120mm×1000mm	40pcs/80pcs	99.95%	As Rolled
MG2030-1129	、、	0.1mm ×200mm×200mm	200pcs/400pcs	99.95%	As Rolled
MG2030-1145	、、	0.1mm ×300mm×300mm	200pcs/400pcs	99.95%	As Rolled
MG2030-1190	、、	0.2mm ×100mm×100mm	300pcs/600pcs/1200pcs	99.95%	As Rolled
MG2030-1200	、、	0.2mm ×150mm×150mm	300pcs/600pcs/1200pcs	99.95%	As Rolled
MG2030-1260	、、	0.2mm ×300mm×300mm	300pcs/600pcs/1200pcs	99.95%	As Rolled
MG2030-1280	、、	0.25mm ×90mm×90mm	50pcs/100pcs/200pcs	99.95%	As Rolled
MG2030-1302	、、	0.25mm ×150mm×150mm	300pcs/600pcs/1200pcs	99.95%	As Rolled
MG2030-1309	、、	0.25mm ×300mm×300mm	300pcs/600pcs/1200pcs	99.95%	As Rolled
MG2030-1735	Magnesium Sheet	0.5mm ×100mm×100mm	100pcs/200pcs	99.95%	As Rolled
MG2030-1787	Magnesium Sheet	0.5mm ×120mm×500mm	100pcs/200pcs	99.95%	As Rolled
MG2030-2312	Magnesium Sheet	0.8mm ×100mm×100mm	100pcs/200pcs	99.95%	As Rolled
MG2030-2346	、、	0.8mm×120mm×500mm	100pcs/200pcs	99.95%	As Rolled
MG2030-4514	High Pure Magnesium Sheet	1.0mm ×100mm×100mm	10pcs/20pcs/50pcs	99.999%(5N)	Polished
MG2030-5130	High Pure Magnesium Sheet	2.0mm ×150mm×150mm	10pcs/20pcs/50pcs	99.999%(5N)	Polished
MG2030-5330	、、	2.0mm ×250mm×250mm	20PC/50PC	99.999%(5N)	As Rolled
MG2030-7233	、、	5.0mm ×300mm×300mm	10PC/20PC/50PC	99.999%(5N)	As Rolled
MG2030-8009	High Pure Magnesium Plate	10mm ×300mm×300mm	10PC/20PC/50PC	99.999%(5N)	As Rolled
MG2030-8612	High Pure Magnesium Plate	15mm ×500mm×500mm	10PC/20PC/50PC	99.999%(5N)	As Rolled
MG2030-8999	、、	20mm ×500mm×500mm	10PC/20PC/50PC	99.999%(5N)	As Rolled
MG2030-D1120	Magnesium Disc	Dia.4mm×0.03mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1125	Magnesium Disc	Dia.6mm×0.03mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1129	Magnesium Disc	Dia.8mm×0.03mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1134	、、	Dia.10mm×0.03mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1137	、、	Dia.12.5mm×0.03mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1141	、、	Dia.15mm×0.03mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1150	、、	Dia.20mm×0.03mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1312	、、	Dia.4mm×0.05mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1317	、、	Dia.6mm×0.05mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1343	、、	Dia.8mm×0.05mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1350	、、	Dia.10mm×0.05mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1355	、、	Dia.12.5mm×0.05mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1359	、、	Dia.15mm×0.05mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D1367	、、	Dia.20mm×0.05mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2110	、、	Dia.10mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2125	、、	Dia.12.5mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2150	、、	Dia.15mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2155	、、	Dia.20mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2160	、、	Dia.25mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2170	、、	Dia.50mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2175	、、	Dia.75mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2180	、、	Dia.100mm×0.1mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2110	、、	Dia.10mm×0.2mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2250	、、	Dia.12.5mm×0.2mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2260	、、	Dia.15mm×0.2mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2275	、、	Dia.20mm×0.2mm	10PC/20PC/50PC	99.95%	Polished
MG2030-D2285	、、	Dia.25mm×0.2mm	10PC/20PC/50PC	99.95%	Polished
MG2030-W7990	Magnesium Wire	Dia.2.0mm×Length	50m/100m/200m/500m	99.99%	As Drawn
MG2030-R8217	High Pure Magnesium Rod	Dia.10mm×500mm	10PC/20PC/50PC	99.999%	As Drawn
MG2030-R8234	High Pure Magnesium Rod	Dia.15mm×500mm	10PC/20PC/50PC	99.999%	As Drawn
MG2030-R8259	High Pure Magnesium Rod	Dia.33mm×500mm	10PC/20PC/50PC	99.999%	As Drawn
MG2030-R8772	High Pure Magnesium Rod	Dia.50.8mm×500mm	10PC/20PC/50PC	99.999%	As Drawn
Magnesium Oxide-Single Crystal Substrate
MG2030-MgO51	Single Crystal Substrate	10mm ×10mm×0.5mm	1PC/5PC	99.99%	Orientation 100, One Side Polished
MG2030-MgO52	Single Crystal Substrate	20mm ×20mm×0.5mm	1PC/5PC	99.99%	Orientation 100, One Side Polished
MG2030-MgO54	Single Crystal Substrate	40mm ×40mm×0.5mm	1PC/5PC	99.99%	Orientation 100, One Side Polished
